EAL Allen Bradley PLC Industrial Maintenance & Fault Finding Pro (IMFFP®) 1&2
What You'll Learn
How to troubleshoot and modify programs in Live Allen Bradley PLCs safely and effeciently to help reduce downtime on the shop-floor.
Background to the PLC, computer numbering systems, Allen Bradley PLC range, PLC hardware and wiring.
How to create and setup a Allen Bradley RSLogix/Studio 5000 or RSLogix 500 project, incl. I/O Configuration, Communications and creating programs.
How to use Allen Bradley Timers, Counters and other commonly used instructions.
How to Download, Upload and Verifiy your programs with a Live Allen Bradley PLC.
Using commonly used Allen Bradley Tools such as Cross-References and Allen Bradley Diagnostics.
Course Information & Topics
We have been working closely with EAL to help develop the first EAL recognised IMFFP® courses that are essential for anyone who intends to be working at an industrial level with PLCs (Programmable Logic Controllers).
Our IMFFP® training course is for anyone who is interested in working with PLCs on the shop-floor while being able to fault find, make modifications and maintain the machinery/production line.
Upon completing the IMFFP® training course, you will able to work with live PLC's in industrial environments while not compromising safety or increasing production downtime when working on the shop-floor. Based around RSLogix 500 or RSLogix/Studio 5000, we will walk through the software and the majority of its available programming instructions that are most used throughout programs on the shop-floor. You will learn how to read industrial programs and incorporate instructions into Programming Blocks, Sub-Routines, and Add-on Instructions. We will explain the Standard Operating Procedures for working on the shop-floor with PLC’s, ensuring you are working safely and efficiently. Fault Finding methods and techniques are then demonstrated and practiced, making you more pro-active when working on processes/machinery, increasing production efficiency and reducing downtime.
At the end of the IMFFP® training course, you are expected to have a detailed understanding of the most used instructions and routines in programming, as well as being confident in approaching, maintaining and fault finding with the PLC in all situations.
1-Year eLearning Access
We understand that once you leave a training course, it may be difficult to follow-up and continuously develop your new skill-set, which is why we are happy to help refresh your training in your own time, whenever you want.
Once you have completed our EAL IMFFP PLC training, you will receive access to our Allen Bradley RSLogix 5000 eLearning training course (Available for up to 1 year), this will allow you to practice what you have been taught on our training course from home or work ensuring your training investment isn't wasted.
Background to the PLC
PLCs in Industry and where they are used
Understanding PLC Numbering Systems and converting between them (Binary, Decimal, Hexadecimal, Octal)
Understanding the Allen Bradley PLC Range
Understanding the differences between Modular, Compact and Rack-based PLCs
How to select a model of PLC for a control system
How to use the Rockwell/Allen Bradley website and locate important areas
Understanding what an Allen Bradley PSU is
Understanding the Allen Bradley CPU and its features
Understanding the Allen Bradley CPU LED indication and error displays
Understanding how to use the CPU Mode Selector
What is a PLC Battery and why is it important
Understanding the Allen Bradley Digital Input and Output Cards
The importance of the Allen Bradley Catalog Numbers and F/W Revisions
How to wire the Allen Bradley PSU, CPU and Input/Output Cards
Understanding the differences between NPN and PNP wiring
Understanding how Modular PLCs are constructed and expanded
Increasing process control via Networking
Understanding basic PLC components
Understanding the differences between Steps, Rungs and Networks
Understanding Logic terminology (AND, OR, ANDN, ORN, EOR)
Understanding the Allen Bradley PLC hardware and internal addressing
The importance of the PLC Scan and how it can be increased
Understanding what PC/Laptop Operating System you should use for RSLogix 500/RSLogix 5000
Understanding the RSLogix 500/RSLogix 5000 environment
Creating your first project
Setting up communications between your Laptop and PC (Serial or USB)
Setting up Hardware Configuration and why its important
How to download safely to the PLC without accidentally shutting down production
Using RSLogix 500/RSLogix 5000 to create your first programming routines
Labelling your project with Tags and Aliases and the benefits of doing so
Understanding Online Editing and the dangers
Understanding the differences between Control Latches and Alarm Latches and their important signals
Understanding the dangers of duplication
Using RSLogix 500/RSLogix 5000 to create Timer delay routines using the variations of Allen Bradley Timers available
Understanding the differences between PLC programming languages and the positives and negatives of each
Understanding the IEC 61131-3 Programming Standards and why we adhere to these standards
Understanding Allen Bradley Counters and what we can use them for
How to use programming instructions to monitor system equipment for maintenance
Understanding what downtime is and how to prevent downtime on the shop-floor
Undertaking an Upload and how to do so correctly
Understanding the dangers of the PLC scan and how it can affect your programs
Understanding the dangers of when working with PLCs and how to work with them safely to prevent accidents in industry
Understanding data handling with the Move instruction
How the PLC works with negative values and 2's complement
Understanding Analogue values and how they are inputted to the PLC
How to convert Analogue signalling from Raw to Engineering and Engineering to Raw
Understanding the common Bit Logic instructions in the Allen Bradley catalog
How to use the One Shot Pulse (Rising and Falling) instructions correctly inside of the Allen Bradley PLC
Using Set and Reset inside of the PLC and why it can be dangerous when used incorrectly
How to undertake a PLC IO Test at the start of commissioning and installing a program
Understanding the use of clock memory of the Allen Bradley PLC
Adopting practices to help reducing downtime when fault finding on a PLC
Using Allen Bradley Cross-References to navigate through your program when fault finding
How to locate free addressing inside of the Allen Bradley PLC
Understanding the Allen Bradley Call Structure
Using verification to ensure accurate backups are available
Understanding the affects that Modifying and Forcing I/O has on the PLC
Understanding the dangers of Forcing Inputs and Outputs in your program
Adopting advanced backup procedures
Understanding how to monitor your programs more effectively
How to locate intermittent faults in a program
Using the Always On and Always Off flags effectively
Using Allen Bradley PLC diagnostics to locate problems in the PLC
Using Safety Interlocking to help increase the integrity of your programs
Understanding interrupts and background routines
How to create Add-on Instructions to further increase your program control
How to create Alarms inside of the PLC and how to manage these within your program
Understanding the different types of CPU Faults
Understanding how to replace a PLC battery on the shop-floor correctly
Understanding how to replace faulty Input/Output cards
Understanding how to replace a PLC memory card on the shop-floor correctly
Understanding how to work with E-Stops and Safety Circuits and implement these inside of your program
Understanding the differences between standard PLCs and safety PLCs
Using Maths instructions inside of the PLC
Using Functions for calculations and data handling giving you further control of your program
Understanding the PLC electrical schematics and IO schedules and why we use these when commissioning and installing programs
Practice fault finding techniques by working with a real industrial program which is currently being used on the shop-floor with the help of your tutor
Understanding the use of sequencers inside of programs and how they can reduce downtime
Understanding the use of a cycle stop routine inside of a program
Using Comparators to monitor process safety limits
Understanding the further differences between PACs and PLCs
Understanding preventative maintenance techniques to be used with the PLC
Learn how to replace an Input/Output Card on a Live PLC System
How to protect your career when working with PLCs
Understanding SIL levels when working with a control system
Understanding IEC Safety Standards when working with a control system
Understanding the dangers of erratic signalling
Identifying faults inside of real industrial programs and how they can be prevented
Understanding best practice programming
Learn how to replace a CPU on a Live PLC System
Make changes to a real industrial program safely without affecting the control system
This Course Includes:
- 4 Days of PLC Training
- EAL Recognised Certification
- EAL Assessments
- Access to Live Allen Bradley PLCs
- Access to Allen Bradley RSLogix/Studio 5000 or RSlogix 500
- Face-to-Face Tuition
- Scantime Training Manual
- 1-Year Access to our Allen Bradley eLearning Courses for Continuous Development
- Special Fixed Rates at the Delta Hotel by Marriott & Holiday Inn Express
EAL Recognised Certification
EAL Centre Code: C001368 - We are approved as an officially recognised EAL Training Centre to provide recognised PLC training courses. EAL is the specialist awarding organisation for the engineering, manufacturing and professional trades sectors.
Access to Live Allen Bradley PLC Systems and RSLogix/Studio 5000 or RSLogix 500
Connect and work with our Live Allen Bradley PLC control systems via Allen Bradley RSLogix/Studio 5000 or RSLogix 500 in classrooms that are dedicated to help you gain unrivalled hands-on experience.
Face-to-Face Tuition from Engineers
We believe to run an engaging and effective PLC training course that relates to those attending, tutors need to have current real-world experience in working with live PLCs, which is why throughout your training, you'll be learning from our PLC experts who are are actively working in industry with our Automation department. This ensures you are learning best-practice PLC maintenance and troubleshooting methods/techniques which are up-to-date and are currently used on shop-floors by Engineers, today.
During your training, you'll have access to your own Scantime Training Manual. Each training manual includes interactive elements which are designed to help you stay engaged. These training manuals will be yours to take home, allowing you to refresh your new skill-set once you have completed our IMFPP® training course.
1-Year eLearning Access
We understand that once you leave a training course, it may be difficult to follow-up and continuously develop your new skill-set, which is why upon completion of our City & Guilds IMFFP training, you'll receive 1-year access to our Allen Bradley RSLogix 5000 eLearning training course, allowing you to practice what you've been taught on our training course from home or work ensuring your training investment isn't wasted.
Special Fixed Rates at the Delta Hotel by Marriott (Metrocentre)
We’re happy to announce that we've been working closely with the Delta Hotel by Marriot Metrocentre located less than 1 mile from our training centre, to help guarantee a fixed rate for Scantime trainees who will be travelling and requiring accommodation during their training course.
With this new partnership, we can offer you a very competitive rate at the Delta Hotel by Marriot Metrocentre which includes certain benefits such as:
• Complimentary parking
• Complimentary WiFi
• Complimentary breakfast
• Use of the Marriot leisure club facilities including gym, sauna and indoor heated pool
• Flexibility to cancel your booking without charges up to 24 hours prior to arrival
Contact us for booking information.
This training course includes examination periods throughout the week of training, which will be 2 x practical assessments and 2 x theoretical assessments. We will also be including additional training time should anyone request further explanation of any topics covered.
Upon completion of our IMFFP® course you will receive an Official EAL Training Certificate, this is proof that the learner has successfully completed a recognised training course at a Recognised EAL Training Centre and has passed all of the assessments for the training course.
